1/3" 1.39mm 5Megapixel M12 mount wide-angle 185degree fisheye lens for panoramic cameras

Name: 13quot 139mm 5Megapixel M12 mount wideangle 185degree fisheye lens for panoramic cameras
Brand: CCOM LENS
Price: 1 USD

Quality 1/3" 1.39mm 5Megapixel M12 mount wide-angle 185degree fisheye lens for panoramic cameras for sale

Place of Origin : China

Model Number : 130139MP-A / 130139MP-B

Packaging Details : Standard

Delivery Time : 2-7 work days

Supply Ability : Samples available

Payment Terms : T/T, Western Union, Moneygram, Paypal

Brand Name : CCOM LENS

MOQ : 100pcs

Board Lens : M12 Mount Fisheye Lens

Resolution : 5MP

FOV : 185degree

Materials : Metal + Glass

Contact Now

1/3" 1.39mm F1.8/F2.0 5Megapixel M12*0.5 mount wide angle 185degree fisheye lens for panoramic cameras

MODEL 130139MP-A
IMAGE FORMAT 1/3" CCD/CMOS
FOCAL LENGTH(mm) 1.39 ±5%
F.O.V. 185°(D)x185°(H)x185°(V)
RESOLUTION 5MP
APERTURE 2.0 ±5%
MOUNT(mm) M12x0.5
IRIS Fixed
M.O.D.(m) 0.1
B.F.L.(mm) 4.05 ±5% (in air)
F.B.L.(mm) 3.50 ±5%

CONSTRUCTION 6G
DIMENSION(mm) Φ17x15.9

MODEL 130139MP-B
IMAGE FORMAT 1/3" CCD/CMOS
FOCAL LENGTH(mm) 1.39 ±5%
F.O.V. 185°(D)x185°(H)x185°(V)
RESOLUTION 5MP
APERTURE 2.0 ±5%
MOUNT(mm) M12x0.5
IRIS Fixed
M.O.D.(m) 0.1
B.F.L.(mm) 4.05 ±5% (in air)
F.B.L.(mm) 3.50 ±5%

CONSTRUCTION 6G
DIMENSION(mm) Φ20x15.9

Tips:
- ***MP: without IR-Cut filter
- ***MPF: with IR-Cut filter
- 650nm/850nm/940nm IR filter optional

- For more fisheye lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com

EFFECT ON 1/3" SENSOR:

1/3" 1.39mm 5Megapixel M12 mount wide-angle 185degree fisheye lens for panoramic cameras

1/3" 1.39mm 5Megapixel M12 mount wide-angle 185degree fisheye lens for panoramic cameras Images
